Provides a roof mounting attachment point for the array.

Listed to UL 2703 and UL 2582

Provides waterproofing for Mounting Block.

Listed to UL 2703 and UL 2582

Part #850-1628*

*Where required, use Flashing Accessory 850-1634, Listed to UL 2703 and UL 2582.

Part #850-1631-002 (4.75”)

Part #850-1631-004 (5.5”)**

**5.5-inch lag must be used for roofs with skip sheathing

Secures PV Modules to the Comp Mount and enables fine-tuned leveling.

Listed to UL 2703

Provides structural and electrical bonding between PV modules within each sub-array.

Listed to UL 2703

Part #850-1388 or

Part #850-1613

Provides structural and electrical bonding.

Listed to UL 2703

Provides a single point for grounding a PV array.

Listed to UL 467 and UL 2703

The Array Skirt serves as an aesthetic feature for the front of the PV array.

Listed to UL 2703

The Grip provides structural support to the Array Skirt.

Listed to UL 2703

(Outside) Part #850-1642

(Inside) Part #850-1641

The Double Key Zep assembly is used to install the array skirt to the side of the array.

Listed to UL 2703

Secures up to 3 conductors underneath a Tesla Zep Compatible™ PV array.

Listed to UL 1565

Secures up to 5 conductors underneath a Tesla Zep Compatible™ PV array.

Listed to UL 1565
